Flame Retardant Polycarbonate Film & Sheet
Gaea Flame Retardant Polycarbonate film & sheet are black, Meet to the ROHS directive and have UL 94 listing. It is widely used in power supply，TV/monitors，business equipments and foil laminated for insulation and shielding purposes.
| Grades | Color | Textures | Thicknesses | Widths |
| FRPC-42-870 | Black | Matte/Velvet |
0.075-0.175 (0.003''～0.007'') |
930 & 1220 (3'& 4') |
| FRPC-42-880 | Black | Matte/Velvet | 0.25（0.01"） | |
| FRPC-42-890 | Black | Fine matte/Velvet |
0.380～1.0 （0.015"～0.040"） |
|
| PC-21-870 | Black | Polished/Matte |
0.075-0.200 （0.003"～0.008"） |
Note: 1220mm width available upon order.
Typical Property Values
| Properties | Test Methods | Units | Values | |
| PHYSICAL | ||||
| Specific Gravity | ASTM D792 | g/cm3 | 1.32 | |
| Water Absorption Equilibrium，24 HRS | ASTM D570 | % | 0.35 | |
| MECHANICAL | ||||
| Tensile Strength | ASTM D882 | psi | 7,300 | |
| MPa | 50 | |||
| Elongation at break | ASTM D882 | % | >25 | |
| Impact Strength @ 30mils | JIS-K6745 | In-lbs | 60 | |
| Tear Strength Propagation | ASTM D1922 | g/mil | >30 | |
| folding times(MIT) | @0.25mm | ASTM D2176-69 | double folds | 30 |
| @0.5mm | ASTM D2176-69 | double folds | 12 | |
| THERMAL | ||||
| Vicat Softening Temperature | ASTM D1525 | ℃ | 135 | |
| Heat shrinkage @135℃ | ASTM D1204 | % | <1.0< span=""> | |
| ELECTRICAL | ||||
| Dielectric Strength (@ 10mils) | ASTM D149 | V/mil | 1,300 | |
| Volume Resistivity@25℃,50%RH | ASTM D257 | Ohm-cm | 1016 | |
| Surface Resistivity@25℃,50%RH | ASTM D257 | Ω/□ | 1015 | |
| FLAMMABILITY | ||||
| UL Flammability | UL BULLETIN 94 | |||
| @＜10 mils | UL94 | VTM-0 | ||
| @≥10 mils | UL94 | V-0 | ||
| Environment-Protection Index | FRPC-42-870/880/890 | FRPC-21-870 |
| Hg | N.D（＜2ppm） | N.D（＜2ppm） |
| Cr(Ⅵ) | N.D（＜2ppm） | N.D（＜2ppm） |
| Cd | N.D（＜2ppm） | N.D（＜2ppm） |
| Pb | N.D（＜2ppm） | N.D（＜2ppm） |
| PBB | N.D（＜5ppm） | ≤300ppm |
| PBDE | N.D（＜5ppm） | ≤300ppm |
